Datos de la referencia:
Lado de montaje: Eje delantero
corona de agujeros - Ø [mm]: 55 mm
Altura [mm]: 49,6 mm
Diámetro [mm]: 274,9 mm
Espesor de disco de frenos [mm]: 25 mm
Espesor mínimo [mm]: 23 mm
Tipo de disco de frenos: ventilado
Referencias OEM:
TOYOTA: 4351213020, 4351213021, 4351213022
TOYOTA (FAW): 4351202230
VW (SVW): 18D698151
Intercambiabilidades:
AKEBONO: BN-0871E,BN-0871E,BN-0871,BN-0871
AKRON-MALÒ: 1110459,1110459,1110459
AP: 25082,25082,25082
APEC braking: DSK2222,DSK2222,DSK2222
ASHIKA: 60-02-219,60-02-219,60-02-219,60-02-219,60-02-219
ASHUKI: 0990-1412
AUTOMOTOR France: PBP4234
BLUE PRINT: ADT343153
BORG & BECK: BBD4381,BBD4381,BBD4457,BBD4457,BBD4457
BRAXIS: AE0571
BRECO: BS 8688,BS 8688,BS 8688
BREMBO: 09.9790.20,09.9790.20,09.9790.20
BREMSI: DBB388V,DBB388V,DBB388V,DBB388V,DBB461V,DBB388V,DBB461V
CHAMPION: 562436CH,562436CH,562436CH,562436CH,562436CH
COMLINE: AND6601,ADC01118V,AND6601,AND6601,ADC01118V,ADC01118V
DJ PARTS: BD2632
DON: PCD15852,PCD15852,PCD15852
EUROBRAKE: 5815204580,5815204580,5815204580
FARCOM: 231264,231264,231264
FERODO: DDF1388,DDF1388,DDF1388,DDF1388,DDF1388
GIRLING: 6043661
HELLA: 8DD 355 115-741,8DD 355 115-741,8DD 355 115-741
HELLA PAGID: 8DD 355 115-741,8DD 355 115-741,8DD 355 115-741
IPS Parts: IBT-1219,IBT-1219
JAPKO: 60219,60219,60219,60219,60219
JP GROUP: 4863101100,4863101100,4863101100
JURID: 562436J,562436JC,562436J,562436JC,562436J,562436JC,562436J,562436J,562436JC,562436JC
KAISHIN: CBR153,CBR153,CBR153
KAVO PARTS: BR-9420-C,BR-9420-C,BR-9420-C
KAWE: 6704 10,6704 10
LPR: T2002V,T2002V,T2002V,T2002V
MAGNETI MARELLI: 360406058500,360406058500,360406058500
MAPCO: 15569
MAXGEAR: 19-3349,19-3349,19-3349
MAXTECH: 861237.0060,861237.6980,861237.0000,861237.6880,861237.0000,861237.6880,861237.6060,861237.6060,861237.0080,861237.0080,861237.0060,861237.6980
MINTEX: MDC2088,MDC2088,MDC2088
NK: 204580,314580,204580,314580,204580,314580
OPEN PARTS: BDA2155.20,BDRS2155.25,BDRS2155.25,BDA2155.20,BDR2155.20,BDRS2155.25,BDA2155.20,BDR2155.20,BDR2155.20
OPTIMAL: BS-7996C,BS-7996
PROTECHNIC: PRD2731,PRD2731,PRD2731
QUATTRO FRENI: QF61000
RAICAM: RD00824,RD00824,RD00824
REMSA: 6704.10,6704.10
REMY: RAD1937,RAD1937C,RAD1937,RAD1937,RAD1937C,RAD1937C
ROADHOUSE: 6704.10,6704.10
SASIC: 6106327,6106327,6106327
sbs: 1815204580,1815314580,1815204580,1815314580,1815314580,1815204580
STELLOX: 6020-4580VK-SX,6020-4580V-SX,6020-4580V-SX,6020-4580VK-SX,6020-4580VK-SX,6020-4580V-SX
TEXTAR: 92180303,92180303,92180303
TRW: DF4366
VAICO: V70-80012
VALEO: 197369,197369,197369
VEMA: 98774,98774
WOKING: D6704.10,D6704.10
Compatibilidades:
TOYOTA:
COROLLA Estate (_E11_) (04/1997-10/2001):
2.0 D-4D (CDE110_) 90CV (09/2000-10/2001) 200110 Diésel (1CD-FTV)
COROLLA (_E12_) (01/2001-12/2007):
2.0 D-4D (CDE120_) 90CV (01/2002-12/2006) 200612 Diésel (1CD-FTV)
COROLLA Saloon (_E12_) (08/2000-03/2008):
2.0 D-4D (CDE120_) 90CV (01/2002-12/2006) 200612 Diésel (1CD-FTV)
COROLLA Estate (_E12_) (03/2001-12/2008):
2.0 D-4D (CDE120_) 90CV (01/2002-02/2007) 200702 Diésel (1CD-FTV)
2.0 D-4D (CDE120_) 116CV (04/2004-02/2007) 200702 Diésel (1CD-FTV)
COROLLA Verso (_E12_) (07/2001-07/2004):
2.0 D-4D (CDE120_) 90CV (01/2002-05/2004) 200405 Diésel (1CD-FTV)
1.8 VVT-i (ZZE122_) 135CV (12/2001-05/2004) 200405 Gasolina (1ZZ-FE)
Motores TOYOTA: 1CD-FTV,1ZZ-FE
