Datos de la referencia:
Lado de montaje: Eje delantero
Diámetro [mm]: 280 mm
Altura [mm]: 142 mm
Tipo de disco de frenos: Macizo
Espesor de disco de frenos [mm]: 16 mm
Espesor mínimo [mm]: 14,5 mm
Diámetro de centrado [mm]: 58,3 mm
Peso [kg]: 13,35 kg
Compatibilidades:
IVECO:
DAILY I Box Body / Estate (01/1978-08/1998):
35-10 (10314204, 10314211, 10314212, 10314217, 10314411,... 92CV (01/1985-12/1989) 198912 Diésel (8140.21.200)
40-10 V 92CV (01/1985-12/1989) 198912 Diésel (8140.27 S)
45-10 V (10334204, 10334211, 10334212, 10334217,... 92CV (01/1985-12/1989) 198912 Diésel (8140.21.200)
49-10 V (10354204, 10354211, 10354212, 10354217,... 92CV (01/1985-12/1989) 198912 Diésel (8140.21.200)
DAILY I Platform/Chassis (01/1978-05/1999):
35-10 (10310311, 10311111, 10311112, 10311117, 10311211,... 92CV (01/1985-12/1989) 198912 Diésel (8140.21.200)
40-10 92CV (01/1985-12/1989) 198912 Diésel (8140.27 S)
45-10 (10331211, 10331212, 10331217, 10331304, 10331311,... 92CV (01/1985-12/1989) 198912 Diésel (8140.21.200)
49-10 (10350211, 10350304, 10350311, 10350404, 10350411,... 92CV (01/1985-12/1989) 198912 Diésel (8140.21.200)
DAILY II Platform/Chassis (01/1989-05/1999):
30-8 (12910211, 12911111, 12911112, 12911117, 12911131,... 75CV (01/1992-08/1998) 199808 Diésel (8140.07.2700)
35-10 (12971112, 12971212, 12971312, 12971317, 12976112,... 92CV (01/1989-12/1996) 199612 Diésel (8140.97.2781)
35-12 (13110131, 13110211, 13110231, 13110311, 13110312,... 116CV (01/1990-04/1996) 199604 Diésel (8140.47.2700)
49-10 (13050211, 13050231, 13050304, 13050311, 13050331,... 103CV (01/1989-04/1996) 199604 Diésel (8140.27.2700)
49-10 (13050211, 13050231, 13050304, 13050311, 13050331,... 103CV (01/1989-04/1996) 199604 Diésel (8140.47R.2790)
49-12 (13130211, 13130231, 13130304, 13130311, 13130312,... 116CV (06/1990-04/1996) 199604 Diésel (8140.47.2711)
49-12 (13130211, 13130231, 13130304, 13130311, 13130312,... 116CV (06/1990-04/1996) 199604 Diésel (8140.47.2721)
49-12 (15150211, 15150311, 15150404, 15150411, 15151204,... 122CV (05/1996-05/1999) 199905 Diésel (8140.43.)
(OTRAS VERSIONES ...)
DAILY II Box Body / Estate (01/1989-05/1999):
30-8 (12914111, 12914112, 12914117, 12914131, 12914137,... 75CV (01/1989-08/1998) 199808 Diésel (8140.07.2700)
30-8 (12914111, 12914112, 12914117, 12914131, 12914137,... 75CV (01/1989-08/1998) 199808 Diésel (8140.07.2712)
30-8 (14914111, 14914117, 14914211, 14914217, 14915111,... 82CV (01/1989-08/1998) 199808 Diésel (8140.67F.)
30-8 (14914111, 14914117, 14914211, 14914217, 14915111,... 82CV (01/1989-08/1998) 199808 Diésel (8140.67F.3710)
30-8 (14914111, 14914117, 14914211, 14914217, 14915111,... 82CV (01/1989-08/1998) 199808 Diésel (8140.67F.3711)
30-8 (14914111, 14914117, 14914211, 14914217, 14915111,... 82CV (01/1989-08/1998) 199808 Diésel (8140.67F.3713)
30-8 (14914111, 14914117, 14914211, 14914217, 14915111,... 82CV (01/1989-08/1998) 199808 Diésel (8140.67F.3721)
35-10 (12974212, 12974217, 13014111, 13014131, 13014204,... 103CV (01/1989-08/1998) 199808 Diésel (8140.47R.2790)
(OTRAS VERSIONES ...)
Motores IVECO: 8140.21.200,8140.27 S,8140.07.2700,8140.97.2781,8140.47.2700,8140.27.2700,8140.47R.2790,8140.47.2711,8140.47.2721,8140.43.,8140.23,8140.67F.,8140.07.2712, ...
