Datos de la referencia:
Tipo de disco de frenos: ventilado
Diámetro [mm]: 276 mm
Espesor de disco de frenos [mm]: 22 mm
Espesor mínimo [mm]: 19 mm
Diámetro de centrado [mm]: 67 mm
Altura [mm]: 60 mm
corona de agujeros - Ø [mm]: 112 mm
Pintura: negro
Superficie: barnizado
SVHC: No hay información disponible, diríjase al fabricante.
Referencias OEM:
MERCEDES-BENZ: 638 421 01 12, A 638 421 01 12, 638421011205
Intercambiabilidades:
A.B.S.: 16887,16887
ABE: C3M015ABE
ATE: 24.0122-0162.1,24.0122-0162.1,24.0322-0162.1,24.0322-0162.1
BARUM: BAR22162,BAR22162
BLUE PRINT: ADU174369
BORG & BECK: BBD4072
BOSCH: 0 986 479 B53,0 986 479 B53,0 986 478 861,0 986 478 861
BREMSI: DBA860V
BSG: BSG 60-210-004,BSG 60-210-004
CHAMPION: 562054CH
CIFAM: 800-416
COMLINE: AND6354,ADC1608V
DENCKERMANN: B130035,B130035,B130035
DIAMAX: N08144
DON: CVD565
DT Spare Parts: 4.62214
FEBI BILSTEIN: 10642
FERODO: DDF860C,DDF860C
fri.tech.: BD0522
FTE: BS4670B,BS4670
GIRLING: 6027971,6027971,6027971
HELLA: 8DD 355 127-231,8DD 355 104-521
HELLA PAGID: 8DD 355 104-521,8DD 355 127-231
ICER: 78BD6380-2
JURID: 562054JC,562054J,562054JC,562054J
KAMOKA: 1031720
KEY PARTS: KBD4072
KLAXCAR FRANCE: 25059z
KRAFT AUTOMOTIVE: 6041400
LEMFÖRDER: 22218 03,22218 03
LPR: M2641V
MAGNETI MARELLI: 353612834240,360406032200
MASTER-SPORT: 24012201621-SET-MS,24012201621-PCS-MS
MAXGEAR: 19-0728MAX,19-0728,19-0728SPORT
MAXTECH: 873561.6060,873561.0000,873561.6880,873561.0080,873561.6060,873561.0060,873561.6980,873561.0080,873561.0000,873561.6880,873561.0060,873561.6980
METELLI: 23-0416
METZGER: 6110407,6110407,6110407
MEYLE: 015 521 2034
MINTEX: MDC1038
PE Automotive: 016.654-00A
PILENGA: V286
QUARO: QD6532
R BRAKE: 78RBD26380
SAMPA: 201.337,201.337
ST-TEMPLIN: 03.110.1926.340
STELLOX: 6020-3335V-SX,6020-3335V-SX,6020-3335VK-SX
STOP: 562054S,562054S
SWAG: 10 91 0642
TEXTAR: 92074403
TOPRAN: 400 857
TRISCAN: 8120 23138,8120 23138C,8120 23138,8120 23138C
TRUCKFRENOS: TF.28.27.1003
TRUSTING: DF522
VAICO: V30-80023,V30-80023
WAGNER: WGR0860-1,WGR0860-1
Compatibilidades:
MERCEDES-BENZ:
VITO Bus (638) (02/1996-07/2003):
108 D 2.3 (638.164) 79CV (02/1996-07/2003) 200307 Diésel (OM 601.942)
110 TD 2.3 (638.174) 98CV (02/1996-07/2003) 200307 Diésel (OM 601.970)
113 2.0 (638.114, 638.194) 129CV (02/1996-07/2003) 200307 Gasolina (M 111.948)
113 2.0 (638.114, 638.194) 129CV (02/1996-07/2003) 200307 Gasolina (M 111.950)
114 2.3 (638.134, 638.194) 143CV (12/1996-07/2003) 200307 Gasolina (M 111.978)
108 CDI 2.2 (638.194) 82CV (03/1999-07/2003) 200307 Diésel (OM 611A (60 KW CDI))
110 CDI 2.2 (638.194) 102CV (03/1999-07/2003) 200307 Diésel (OM 611LA (75 KW CDI))
112 CDI 2.2 (638.194) 122CV (03/1999-07/2003) 200307 Diésel (OM 611.980)
VITO Box (638) (03/1997-07/2003):
108 D 2.3 (638.064, 638.068) 79CV (03/1997-07/2003) 200307 Diésel (OM 601.942)
110 D 2.3 (638.074, 638.078) 98CV (03/1997-07/2003) 200307 Diésel (OM 601.970)
113 2.0 (638.014, 638.094) 129CV (03/1997-07/2003) 200307 Gasolina (M 111.948)
113 2.0 (638.014, 638.094) 129CV (03/1997-07/2003) 200307 Gasolina (M 111.950)
114 2.3 (638.034, 638.094) 143CV (03/1997-07/2003) 200307 Gasolina (M 111.978)
108 CDI 2.2 (638.094) 82CV (03/1999-07/2003) 200307 Diésel (OM 611A (60 KW CDI))
110 CDI 2.2 (638.094) 102CV (03/1999-07/2003) 200307 Diésel (OM 611LA (75 KW CDI))
112 CDI 2.2 (638.094) 122CV (03/1999-07/2003) 200307 Diésel (OM 611.980)
V-CLASS (638/2) (02/1996-07/2003):
V 230 TD (638.274) 98CV (09/1996-07/2003) 200307 Diésel (OM 601.970)
V 230 (638.234, 638.294) 143CV (10/1996-07/2003) 200307 Gasolina (M 111.978)
V 230 (638.234, 638.294) 143CV (10/1996-07/2003) 200307 Gasolina (M 111.980)
V 280 (638.244, 638.294) 174CV (08/1997-07/2003) 200307 Gasolina (M 104.900)
V 200 (638.214, 638.294) 129CV (02/1997-07/2003) 200307 Gasolina (M 111.948)
V 200 (638.214, 638.294) 129CV (02/1997-07/2003) 200307 Gasolina (M 111.950)
V 200 CDI (638.294) 102CV (03/1999-07/2003) 200307 Diésel (OM 611.980)
V 220 CDI (638.294) 122CV (03/1999-07/2003) 200307 Diésel (OM 611.980)
Motores MERCEDES-BENZ: OM 601.942,OM 601.970,M 111.948,M 111.950,M 111.978,OM 611A (60 KW CDI),OM 611LA (75 KW CDI),OM 611.980,M 111.980,M 104.900, ...
